Rockshox ZEB Ultimate Charger 3.1 RC2 A3 With Custom Tuning

Rockshox ZEB Ultimate Charger 3.1 RC2 A3 With Custom Tuning

RSF1075003

£1,159.00
£1,159.00
Sale Sold out
Tax included.
Custom Tuning

Custom tuning, revalving, shim tuning, whatever you like to call it, it's included!
We'll install our tried and tested shims stacks, to suit your application, and rebuild the fork with the best quality oils and low friction additives, as well as resizing bushings for minimal friction. We'll even give you a recommended setup for all the adjusters, as well as air pressure/spring recommendations, and ongoing setup support, if you're not quite getting the most from our initial setup.
You'll get a nice printed sheet, for your reference, enclosed with the fork.
Find Custom Tuning information here

Want to take it to the next level? Why not add the fantastic WPS Podium Piston kit?! Just select the option "w/WPS PPK" in the drop down menu.

Just want a standard fork? Click here to buy now.

Description
Rockshox say:
"Long on travel, short on excuses, ZEB Ultimate is a whole new breed of fork designed to challenge the limits and take on the world’s toughest enduro tracks. An updated stiff 38mm chassis includes the new Charger 3.1 RC2 damper with vibration-killing ButterCup technology. Our highest-performing, athlete-proven technologies are matched with premium style plays. This is ZEB. 

ROCKSHOX FORK ZEB ULTIMATE CHARGER 3.1 RC2 - 29" A3

Built for the best riders, ridden on the hardest tracks, ZEB Ultimate rules the world’s toughest enduros. Equipped with the new Charger 3.1 RC2 damper, ZEB gives riders exceptional adjustability for the right balance of comfort, control, and speed. Alongside this flagship damper, the stout 38mm chassis rides on vibration-killing ButterCups and a DebonAir+ spring. The technology you need for the fastest split times, the style you want on the start line: This is ZEB."

Key Features
  • 38mm chassis for increased stiffness and rider confidence on every critical line.
  • Already proving itself on the podium with multiple wins during the 2021 season, Charger 3.1 is ready to meet the masses. Charger 3.1 features the same Internal Floating Piston (IFP) design from the Charger 3, which offers more consistency through the stroke, and truly independent adjustments that reduce harshness and increase control without any “cross-talk”. Featuring High-Speed Compression, Low-Speed Compression, and a revamped Low-Speed Rebound, every click is exact and meaningful.
  • ButterCups block 20% of high-frequency “trail chatter”. Limiting these vibrations massively reduces hand and arm fatigue leaving you feeling fresh with more control.
  • DebonAir+ air spring is built to strike the perfect balance of what riders really want: a butterlike small bump feel, increased air volume to add support throughout the travel, and higher overall ride height for more confidence when things get steep.
  • Ultimate Bushing Package maximizes bushing overlap, reducing friction and creating the smoothest ride possible.
  • Maxima Plush Dynamic Suspension Lube reduces friction, lasts longer, and enhances suspension performance ride after ride.
  • Bolt-in torque cap adapters are now included for use with standard hub end caps.
  • Lightweight machined and anodized crown for premium looks and durability.
  • Available in the Signature colourway Slab Grey or Ultimate High Gloss Black.
  • Ultra-low friction SKF wiper seals provide long-lasting fork performance and improve overall suspension feel.
  • RockShox premium short fender compatibility. (RockShox bolt-on fender sold separately).
  • Maxima Plush damping fluid reduces friction and silences damper noise.

Specifications

Wheel size: 27.5 or 29".
Travel (mm): 150mm-190mm.
Damper Type: Charger 3 RC2 w/Buttercup
Fork offset: 44mm (27.5") and 44mm(29").
Maxle included: Maxle Stealth.
Colour (FS): Slab Grey Matte or Gloss Black.
Steerer: 1.5" Tapered.
Axle: 15x110mm BOOST™.
Axle to Crown (mm):
Crown Material: Forged, hollow aluminium.
Lower leg material: Magnesium.
Upper Tube Finish: Fast Black.
Upper tube type: 38mm tapered wall aluminium.
Damper adjust: Crown.
Damping adjustments: External beginning stroke rebound, Low and High-speed Compression.
Volume reducer: 2/5 Tokens.
Spring: DebonAir+ W/ButterCups
Rotor Size: 200mm min. 220mm max
Weight: 2341g (29" Maxle Stealth 190mm Travel 1.5" Taper Steerer)
Max Tyre Width: 81mm

Delivery
It will take approx. 5 working days to dispatch your order, as the fork needs to go through the workshop. We'll confirm a dispatch date within 1 working day of you placing your order.

Links
Action Interval
Clean and Lubricate Every Ride
Inspect for scratches to stanchions, dents and other signs of wear Every Ride
Check headset, axle and brake torque Every Ride
Oil Bath Replacement 50hrs use
Wiper Seal Replacement 50hrs use
Full Service Every 100hrs of use / 12 months whichever comes first.
